KT-560M

Catalog index: WMGBKT560M

Thermal imaging camera with fever detection





Req quote

Alert! Fever detected! Examine through image

Sonel KT-560M is dedicated for body temperature measurements. If the temperature exceeds a set threshold (i.e. fever), setting off an alarm is possible.
This way, one can detect risk groups during extensive examinations. The imager can also be used to detect various diseases in individual patients and
animals.

Application

The camera allows to identify people with fever in the crowd (e.g. caused by viral or bacterial infection). Ideally suited for sanitary-epidemiological monitoring
of groups or individual people. In addition, it can be widely used in medicine (neurosurgery, neurology, vascular surgery, dentistry, otolaryngology, pulmonology, endocrinology and mammology) and in veterinary medicine.

The camera is a useful tool when detecting:

  • fever
  • malignant tumours of breast, skin, lymph nodes, facial skeleton and their relapses,
  • inflammation and adenocarcinoma (ovary and fallopian tube),
  • ear, throat and nose inflammation,
  • inflammatory diseases of the joints and spine,
  • diseases of the vessels and nerves of the extremities,
  • thyroid dysfunction and disease,
  • inflammatory and functional diseases of the kidneys, as well as the digestive system and liver,
  • inflammation and diseases in animals.

Features:

  • measuring range 20°C…60°C, accuracy ≤ ±0.4°C
  • 5 Mpix visual camera
  • imaging modes: IR, visual, PIP (picture in picture), MIF (combined visual and IR)
  • saving IR images and videos to SD card or directly to a PC
  • 5’’ large rotating touchscreen
  • built-in report module for complete thermal analysis
  • add voice and text notes, draw graphical symbols on images
  • adjustable brightness of the display, facilitating work at high ambient light and dark places
  • GPS, digital compass, LED flashlight and laser pointer
  • removable Li-Ion battery with 4-hour working time
  • interfaces: microUSB 2.0, Wi-Fi, Gigabit Ethernet, MiniHDMI, SD slot

Specifications

Detector resolution 384 x 288
Detector VOx / 25 μm / 7,5~14 μm
Frame rate 25 Hz / 9 Hz
Sensitivity 40 mK
Lens (field of vision / focal distance) 21.7° x 16.4°/25 mm/F1.0
Spatial resolution (IFOV) 0.99 mrad
Focus Motor-drive / Auto
Display 5″, 1280 x 720, touch-screen LCD
Viewfinder 1280 x 960 LCOS
Image mode IR / Visual / Infrafusion MIF/ PiP
Zoom 1.1…4
Temperature range 20°C…60°C
Accuracy ±0.4°C (32°C…38°C)
±0.6°C (20°C …32°C or 38°C…60°C)
Image analysis mode 5 points, 5 lines, 5 areas
Analysis info storage Saved with image (point, line, areas)
Auto tracking Max. or Min.
Isotherm Upper / Lower
Temperature Alarm Visual and voice
Palettes 8
Palettes 8
Image file format JPG or raw data
Reports module PDF reports, report printing via Wi-Fi
Video file format H.264 (with temperature data)
Video internal storage Manual
Built-in functions 5 Mpix visual photo camera, LED flashlight, GPS,
laser pointer, microphone, speaker, digital compass,
lighting sensor
Wireless communication Wi-Fi
Interfaces SD card port, LAN 1 Gb/s, mini HDMI, microUSB 2.0
Memory 16 GB SD card (max. 32 GB)
Power supply Li-Ion rechargeable battery (operating time >4 hours),
sleep mode, built-in charger,
AC 110-230 V 50/60 Hz power supply
Operating temperature 15°C…35°C
Storage temperature -40°C…+70°C
Humidity 10%…95%
Resistance to shocks / vibrations 25G, IEC 60068-2-29 / 2G, IEC 60068-2-6
Housing IP54
Weight approx. 1.3 kg (with battery)



Data Sheet
